APEX4WD 13500lb 12V Electric Recovery Winch with Synthetic Rope – IP67 Rated
Built for Performance and Durability
This heavy-duty 12V electric recovery winch is engineered for tough recovery tasks. With a powerful 6.5HP pure copper motor, synthetic rope, and IP67 waterproof rating, it’s ideal for off-road adventures, towing, and challenging recovery situations.
Key Features:
- Powerful Motor: 6.5HP pure copper motor for reliable performance.
- High Line Pull: 13,500 lbs rated single-line capacity.
- Waterproof Design: IP67-rated control box for all-weather use.
- Dual Control Options: 3m handheld wired remote and wireless remote for convenience.
- Synthetic Rope: Durable 9mm x 24m synthetic wire rope with fairlead.
- Advanced Gear System: 3-stage planetary gearing with a 265:1 ratio for optimal power and speed balance.
- Automatic Brake: 100% full-load holding mechanical brake for safety.
- Heavy-Duty Build: Steel gears, pull-and-turn clutch handle, and heavy-duty clevis winch hook.
Specifications:
- Rated Line Pull: 13,500 lbs (single line).
- Motor: 4.8kW/6.5HP (series wound).
- Gear System: 3-stage planetary with 265:1 ratio.
- Control Options: Wireless handheld remote + 3m (9.8ft) wired remote.
- Clutch: Mechanical sliding ring gear.
- Drum Dimensions: Φ64mm × 220mm.
- Synthetic Rope: Φ9mm × 24m.
- Winch Dimensions: 630mm × 230mm × 360mm.
- Net Weight: 35kg (Gross Weight: 36kg).
- Mounting Bolt Pattern: 255mm × 114mm, Φ11mm.
- Packaging Dimensions: 610mm × 350mm × 270mm.
Whether you're tackling off-road trails or handling recovery missions, this electric winch offers power, reliability, and ease of use.
